دیتاشیت LT3501EFE#TRPBF
مشخصات دیتاشیت
| نام دیتاشیت |
LT3501
|
| حجم فایل |
450.424
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
30
|
مشخصات
-
RoHS:
true
-
Category:
Power Supply Chip/DC-DC Converters
-
Function:
Step-down type
-
Topology:
Step-down
-
Datasheet:
Analog Devices LT3501EFE#TRPBF
-
Output Type:
Adjustable
-
Input Voltage:
3.1V~25V
-
Output Voltage:
0.8V~23.75V
-
Number of Outputs:
2
-
Switching Frequency:
1.5MHz
-
Output Current (Max):
3A
-
Operating Temperature:
-40°C~+125°C@(TJ)
-
Synchronous Rectification:
NO
-
Package:
TSSOP-20-EP
-
Manufacturer:
Analog Devices
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Output Configuration:
Positive
-
Voltage - Input (Min):
3.1V
-
Voltage - Input (Max):
25V
-
Voltage - Output (Min/Fixed):
0.8V
-
Voltage - Output (Max):
23.75V
-
Current - Output:
3A
-
Frequency - Switching:
250kHz ~ 1.5MHz
-
Synchronous Rectifier:
No
-
Mounting Type:
Surface Mount
-
Package / Case:
20-TSSOP (0.173", 4.40mm Width) Exposed Pad
-
Supplier Device Package:
20-TSSOP-EP
-
Base Part Number:
LT3501
-
detail:
Buck Switching Regulator IC Positive Adjustable 0.8V 2 Output 3A 20-TSSOP (0.173", 4.40mm Width) Exposed Pad
