APTM08TAM04PG دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت APTM08TAM04PG	دانلود دیتاشیت

Manufacturer: Microchip Technology
Series: -
Packaging: Bulk
Part Status: Active
FET Type: 6 N-Channel (3-Phase Bridge)
FET Feature: Standard
Drain to Source Voltage (Vdss): 75V
Current - Continuous Drain (Id) @ 25°C: 120A
Rds On (Max) @ Id, Vgs: 4.5mOhm @ 60A, 10V
Vgs(th) (Max) @ Id: 4V @ 1mA
Gate Charge (Qg) (Max) @ Vgs: 153nC @ 10V
Input Capacitance (Ciss) (Max) @ Vds: 4530pF @ 25V
Power - Max: 138W
Operating Temperature: -40°C ~ 150°C (TJ)
Mounting Type: Chassis Mount
Package / Case: SP6
Supplier Device Package: SP6-P
detail: Mosfet Array 6 N-Channel (3-Phase Bridge) 75V 120A 138W Chassis Mount SP6-P
