LT3482EUD#TRPBF دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت LT3482EUD#TRPBF	دانلود دیتاشیت

RoHS: true
Category: Power Supply Chip/DC-DC Converters
Function: boost converterType
Topology: Boost
Datasheet: Analog Devices LT3482EUD#TRPBF
Output Type: Adjustable
Input Voltage: 2.5V~16V
Output Voltage: 5V~90V
Number of Outputs: 1
Switching Frequency: 1.1MHz
Output Current (Max): 280mA
Operating Temperature: -40°C~+85°C@(TA)
Synchronous Rectification: NO
Package: QFN-16-EP(3x3)
Manufacturer: Analog Devices
Series: -
Packaging: Cut Tape (CT)
Part Status: Active
Output Configuration: Positive
Voltage - Input (Min): 2.5V
Voltage - Input (Max): 16V
Voltage - Output (Min/Fixed): 5V
Voltage - Output (Max): 90V
Current - Output: 280mA (Switch)
Frequency - Switching: 650kHz ~ 1.1MHz
Synchronous Rectifier: No
Mounting Type: Surface Mount
Package / Case: 16-WFQFN Exposed Pad
Supplier Device Package: 16-QFN-EP (3x3)
Base Part Number: LT3482
detail: Boost, Charge Pump Switching Regulator IC Positive Adjustable 5V 1 Output 280mA (Switch) 16-WFQFN Exposed Pad
