دیتاشیت LT3012HFE#TRPBF

LT3012 Datasheet

مشخصات دیتاشیت

نام دیتاشیت LT3012 Datasheet
حجم فایل 187.616 کیلوبایت
نوع فایل pdf
تعداد صفحات 16

دانلود دیتاشیت LT3012 Datasheet

LT3012 Datasheet Datasheet

مشخصات

  • Manufacturer: Linear Technology/Analog Devices
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Output Configuration: Positive
  • Output Type: Adjustable
  • Number of Regulators: 1
  • Voltage - Input (Max): 80V
  • Voltage - Output (Min/Fixed): 1.24V
  • Voltage - Output (Max): 60V
  • Voltage Dropout (Max): 0.63V @ 200mA
  • Current - Output: 200mA
  • Current - Quiescent (Iq): 110µA
  • Current - Supply (Max): 18mA
  • PSRR: 75dB (120Hz)
  • Control Features: Enable
  • Protection Features: Over Current, Over Temperature, Reverse Polarity
  • Operating Temperature: -40°C ~ 140°C
  • Mounting Type: Surface Mount
  • Package / Case: 16-TSSOP (0.173", 4.40mm Width) Exposed Pad
  • Supplier Device Package: 16-TSSOP-EP
  • Base Part Number: LT3012
  • detail: Linear Voltage Regulator IC 1 Output 200mA 16-TSSOP-EP
