دیتاشیت LTC1155IS8#TRPBF

LTC1155 Datasheet

مشخصات دیتاشیت

نام دیتاشیت LTC1155 Datasheet
حجم فایل 2265.566 کیلوبایت
نوع فایل pdf
تعداد صفحات 20

دانلود دیتاشیت LTC1155 Datasheet

LTC1155 Datasheet Datasheet

مشخصات

  • RoHS: true
  • Category: Power Supply Chip/Gate Drive ICs
  • Datasheet: Analog Devices LTC1155IS8#TRPBF
  • Load Type: MOSFET
  • Rise Time: -
  • Supply Voltage: 4.5V~18V
  • Number of Drivers: 2
  • Driven Configuration: High Side
  • Operating Temperature: -40°C~+85°C@(Ta)
  • Peak Output Current(sink): -
  • Package: SOIC-8
  • Manufacturer: Analog Devices
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Channel Type: Independent
  • Gate Type: N-Channel MOSFET
  • Voltage - Supply: 4.5V ~ 18V
  • Logic Voltage - VIL, VIH: 0.8V, 2V
  • Current - Peak Output (Source, Sink): -
  • Input Type: Non-Inverting
  • Rise / Fall Time (Typ): -
  • Mounting Type: Surface Mount
  • Package / Case: 8-SOIC (0.154", 3.90mm Width)
  • Supplier Device Package: 8-SOIC
  • Base Part Number: LTC1155
  • detail: High-Side Gate Driver IC Non-Inverting 8-SOIC
