دیتاشیت LTC3703EGN-5#TRPBF

مشخصات دیتاشیت

دانلود دیتاشیت LTC3703-5	LTC3703-5 Datasheet

Manufacturer: Linear Technology/Analog Devices
Series: -
Packaging: Cut Tape (CT)
Part Status: Active
Output Type: Transistor Driver
Function: Step-Down
Output Configuration: Positive
Topology: Buck
Number of Outputs: 1
Output Phases: 1
Voltage - Supply (Vcc/Vdd): 4.1V ~ 15V
Frequency - Switching: 100kHz ~ 600kHz
Duty Cycle (Max): 93%
Synchronous Rectifier: Yes
Clock Sync: Yes
Serial Interfaces: -
Control Features: Current Limit, Enable, Frequency Control, Soft Start
Operating Temperature: -40°C ~ 85°C (TA)
Mounting Type: Surface Mount
Package / Case: 16-SSOP (0.154", 3.90mm Width)
Supplier Device Package: 16-SSOP
Base Part Number: LTC3703
detail: Buck Regulator Positive Output Step-Down DC-DC Controller IC 16-SSOP
