- دیتاشیت LTpowerCAD II Quick Start Guide
LTpowerCAD II Quick Start Guide دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | LTpowerCAD II Quick Start Guide |
|---|---|
| حجم فایل | 3567.647 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 36 |
دانلود دیتاشیت LTpowerCAD II Quick Start Guide |
دانلود دیتاشیت |
|---|
سایر مستندات
LTpowerPlanner III Quick Start Guide 40 pages
LTpowerCAD II User Guide 60 pages
LT3724 26 pages
LT3724IFE#PBF 26 pages
مشخصات فنی
- RoHS: true
- Category: Power Supply Chip/DC-DC Controllers
- Function: boost converterType;Step-down type;Buck-boost type
- Topology: Step-down;Boost;SEPIC
- Datasheet: Analog Devices LT3724EFE#TRPBF
- Input Voltage: 4V~60V
- Duty Cycle (Max): -
- Number of Outputs: 1
- Switching Frequency: 200kHz
- Operating Temperature: -40°C~+125°C@(TJ)
- Synchronous Rectification: NO
- Package: TSSOP-16-EP
- Manufacturer: Analog Devices
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Output Type: Transistor Driver
- Output Configuration: Positive or Negative
- Output Phases: 1
- Voltage - Supply (Vcc/Vdd): 4V ~ 60V
- Frequency - Switching: 200kHz
- Synchronous Rectifier: No
- Clock Sync: No
- Serial Interfaces: -
- Control Features: Enable, Soft Start
- Mounting Type: Surface Mount
- Package / Case: 16-TSSOP (0.173", 4.40mm Width) Exposed Pad
- Supplier Device Package: 16-TSSOP-EP
- Base Part Number: LT3724
- detail: Buck, Boost, SEPIC Regulator Positive or Negative Output Step-Up, Step-Down, Step-Up/Step-Down DC-DC Controller IC 16-TSSOP-EP
