دیتاشیت LT3991IMSE#TRPBF
مشخصات دیتاشیت
| نام دیتاشیت | LT3991(-3.3,-5) |
|---|---|
| حجم فایل | 398.285 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 24 |
دانلود دیتاشیت LT3991(-3.3,-5) |
LT3991(-3.3,-5) Datasheet |
|---|
مشخصات
- Manufacturer: Linear Technology/Analog Devices
- Series: -
- Part Status: Active
- Function: Step-Down
- Output Configuration: Positive
- Topology: Buck
- Output Type: Adjustable
- Number of Outputs: 1
- Voltage - Input (Min): 4.3V
- Voltage - Input (Max): 55V
- Voltage - Output (Min/Fixed): 1.19V
- Voltage - Output (Max): 30V
- Current - Output: 1.2A
- Frequency - Switching: 200kHz ~ 2MHz
- Synchronous Rectifier: No
- Operating Temperature: -40°C ~ 125°C (TJ)
- Mounting Type: Surface Mount
- Package / Case: 10-TFSOP, 10-MSOP (0.118", 3.00mm Width) Exposed Pad
- Supplier Device Package: 10-MSOP-EP
- Base Part Number: LT3991
- detail: Buck Switching Regulator IC Positive Adjustable 1.19V 1 Output 1.2A 10-TFSOP, 10-MSOP (0.118", 3.00mm Width) Exposed Pad
