APTGT150SK170G دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت APTGT150SK170G	دانلود دیتاشیت

Manufacturer: Microchip Technology
Series: -
Packaging: Bulk
Part Status: Active
IGBT Type: Trench Field Stop
Configuration: Single
Voltage - Collector Emitter Breakdown (Max): 1700V
Current - Collector (Ic) (Max): 250A
Power - Max: 890W
Vce(on) (Max) @ Vge, Ic: 2.4V @ 15V, 150A
Current - Collector Cutoff (Max): 350µA
Input Capacitance (Cies) @ Vce: 13.5nF @ 25V
Input: Standard
NTC Thermistor: No
Operating Temperature: -40°C ~ 150°C (TJ)
Mounting Type: Chassis Mount
Package / Case: SP6
Supplier Device Package: SP6
detail: IGBT Module Trench Field Stop Single 1700V 250A 890W Chassis Mount SP6
