APTM120A29FTG دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت APTM120A29FTG	دانلود دیتاشیت

Manufacturer: Microchip Technology
Series: -
Packaging: Bulk
Part Status: Active
FET Type: 2 N-Channel (Half Bridge)
FET Feature: Standard
Drain to Source Voltage (Vdss): 1200V (1.2kV)
Current - Continuous Drain (Id) @ 25°C: 34A
Rds On (Max) @ Id, Vgs: 348mOhm @ 17A, 10V
Vgs(th) (Max) @ Id: 5V @ 5mA
Gate Charge (Qg) (Max) @ Vgs: 374nC @ 10V
Input Capacitance (Ciss) (Max) @ Vds: 10300pF @ 25V
Power - Max: 780W
Operating Temperature: -40°C ~ 150°C (TJ)
Mounting Type: Chassis Mount
Package / Case: SP4
Supplier Device Package: SP4
detail: Mosfet Array 2 N-Channel (Half Bridge) 1200V (1.2kV) 34A 780W Chassis Mount SP4
