دیتاشیت LTC2203IUK#PBF
مشخصات دیتاشیت
| نام دیتاشیت |
LTC2202-03
|
| حجم فایل |
1490.385
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
32
|
مشخصات
-
RoHS:
true
-
Category:
ADC/DAC/Data Conversion/Analog To Digital Converters (ADCs)
-
Datasheet:
Analog Devices LTC2203IUK#PBF
-
Interface:
Parallel
-
resolution:
16Bit
-
Supply Voltage:
3.135V~3.465V
-
differential input:
Yes
-
number of channels:
1
-
sampling frequency:
25MHz
-
Operating Temperature:
-40°C~+85°C
-
Package:
QFN-48-EP(7x7)
-
Manufacturer:
Analog Devices
-
Series:
-
-
Packaging:
Tube
-
Part Status:
Obsolete
-
Number of Bits:
16
-
Sampling Rate (Per Second):
25M
-
Number of Inputs:
1
-
Input Type:
Differential
-
Data Interface:
Parallel
-
Configuration:
S/H-ADC
-
Ratio - S/H:ADC:
1:1
-
Number of A/D Converters:
1
-
Architecture:
Pipelined
-
Reference Type:
External, Internal
-
Voltage - Supply, Analog:
3.135V ~ 3.465V
-
Voltage - Supply, Digital:
3.135V ~ 3.465V
-
Features:
PGA
-
Package / Case:
48-WFQFN Exposed Pad
-
Supplier Device Package:
48-QFN (7x7)
-
Mounting Type:
Surface Mount
-
detail:
16 Bit Analog to Digital Converter 1 Input 1 Pipelined 48-QFN (7x7)
