دیتاشیت LT1940EFE#TRPBF

مشخصات دیتاشیت

دانلود دیتاشیت LT1940(L) Datasheet	LT1940(L) Datasheet Datasheet

RoHS: true
Category: Power Supply Chip/DC-DC Converters
Function: Step-down type
Topology: Step-down
Datasheet: Analog Devices LT1940EFE#TRPBF
Output Type: Adjustable
Input Voltage: 3.6V~25V
Output Voltage: 1.25V~22V
Number of Outputs: 2
Switching Frequency: 1.1MHz
Output Current (Max): 1.4A
Operating Temperature: 0°C~+70°C@(TA)
Synchronous Rectification: NO
Package: TSSOP-16-EP
Manufacturer: Analog Devices
Series: -
Packaging: Cut Tape (CT)
Part Status: Active
Output Configuration: Positive
Voltage - Input (Min): 3.6V
Voltage - Input (Max): 25V
Voltage - Output (Min/Fixed): 1.25V
Voltage - Output (Max): 22V
Current - Output: 1.4A
Frequency - Switching: 1.1MHz
Synchronous Rectifier: No
Mounting Type: Surface Mount
Package / Case: 16-TSSOP (0.173", 4.40mm Width) Exposed Pad
Supplier Device Package: 16-TSSOP-EP
Base Part Number: LT1940
detail: Buck Switching Regulator IC Positive Adjustable 1.25V 2 Output 1.4A 16-TSSOP (0.173", 4.40mm Width) Exposed Pad
