دیتاشیت LTC2353HLX-16#PBF
مشخصات دیتاشیت
| نام دیتاشیت | LTC2353-16 Datasheet |
|---|---|
| حجم فایل | 2143.961 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 38 |
دانلود دیتاشیت LTC2353-16 Datasheet |
LTC2353-16 Datasheet Datasheet |
|---|
مشخصات
- RoHS: true
- Category: ADC/DAC/Data Conversion/Analog To Digital Converters (ADCs)
- Datasheet: Analog Devices LTC2353HLX-16#PBF
- Interface: serial;SPI
- resolution: 16Bit
- Supply Voltage: 7.5V~38V
- differential input: Yes
- number of channels: 2
- sampling frequency: 550kHz
- Operating Temperature: -40°C~+125°C
- Package: LQFP-48(7x7)
- Manufacturer: Analog Devices
- Series: SoftSpan™
- Packaging: Tray
- Part Status: Active
- Number of Bits: 16
- Sampling Rate (Per Second): 550k
- Number of Inputs: 2
- Input Type: Differential, Pseudo-Differential, Single Ended
- Data Interface: LVDS - Serial, SPI
- Configuration: S/H-MUX-ADC
- Ratio - S/H:ADC: 2:1
- Number of A/D Converters: 1
- Architecture: SAR
- Reference Type: Internal
- Voltage - Supply, Analog: 7.5V ~ 38V
- Voltage - Supply, Digital: 4.75V ~ 5.25V
- Features: Simultaneous Sampling
- Package / Case: 48-LQFP
- Supplier Device Package: 48-LQFP (7x7)
- Mounting Type: Surface Mount
- Base Part Number: LTC2353
- detail: 16 Bit Analog to Digital Converter 2 Input 1 SAR 48-LQFP (7x7)
