APTM50AM19FG دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت APTM50AM19FG	دانلود دیتاشیت

Manufacturer: Microchip Technology
Series: -
Packaging: Bulk
Part Status: Active
FET Type: 2 N-Channel (Half Bridge)
FET Feature: Standard
Drain to Source Voltage (Vdss): 500V
Current - Continuous Drain (Id) @ 25°C: 163A
Rds On (Max) @ Id, Vgs: 22.5mOhm @ 81.5A, 10V
Vgs(th) (Max) @ Id: 5V @ 10mA
Gate Charge (Qg) (Max) @ Vgs: 492nC @ 10V
Input Capacitance (Ciss) (Max) @ Vds: 22400pF @ 25V
Power - Max: 1136W
Operating Temperature: -40°C ~ 150°C (TJ)
Mounting Type: Chassis Mount
Package / Case: SP6
Supplier Device Package: SP6
detail: Mosfet Array 2 N-Channel (Half Bridge) 500V 163A 1136W Chassis Mount SP6
