APTGT30A170T1G دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت APTGT30A170T1G	دانلود دیتاشیت

Manufacturer: Microchip Technology
Series: -
Packaging: Bulk
Part Status: Active
IGBT Type: Trench Field Stop
Configuration: Half Bridge
Voltage - Collector Emitter Breakdown (Max): 1700V
Current - Collector (Ic) (Max): 45A
Power - Max: 210W
Vce(on) (Max) @ Vge, Ic: 2.4V @ 15V, 30A
Current - Collector Cutoff (Max): 250µA
Input Capacitance (Cies) @ Vce: 2.5nF @ 25V
Input: Standard
NTC Thermistor: Yes
Operating Temperature: -40°C ~ 150°C (TJ)
Mounting Type: Chassis Mount
Package / Case: SP1
Supplier Device Package: SP1
detail: IGBT Module Trench Field Stop Half Bridge 1700V 45A 210W Chassis Mount SP1
