LTM4627 دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
LTM4627
|
|
حجم فایل
|
582.57
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
32
|
مشخصات فنی
-
RoHS:
true
-
Category:
Power Supply Chip/Power Modules
-
Datasheet:
Analog Devices LTM4627IV#PBF
-
Output Channel:
1
-
Output Voltage:
0.6V~5V
-
Input Voltage(DC):
4.5V~20V
-
Output Current (Max):
15A
-
Conversion Efficiency:
93%
-
Package:
LGA-133
-
Manufacturer:
Analog Devices
-
Series:
µModule®
-
Packaging:
Tray
-
Part Status:
Active
-
Type:
Non-Isolated PoL Module
-
Number of Outputs:
1
-
Voltage - Input (Min):
4.5V
-
Voltage - Input (Max):
20V
-
Voltage - Output 1:
0.6 ~ 5V
-
Voltage - Output 2:
-
-
Voltage - Output 3:
-
-
Current - Output (Max):
15A
-
Applications:
ITE (Commercial)
-
Features:
OCP, OVP
-
Operating Temperature:
-40°C ~ 125°C
-
Efficiency:
93%
-
Mounting Type:
Surface Mount
-
Package / Case:
133-BLGA Module
-
Size / Dimension:
0.59" L x 0.59" W x 0.17" H (15.0mm x 15.0mm x 4.3mm)
-
Supplier Device Package:
133-LGA (15x15)
-
Base Part Number:
LTM4627
-
detail:
Non-Isolated PoL Module DC DC Converter 1 Output 0.6 ~ 5V 15A 4.5V - 20V Input
