دیتاشیت LTC2323IUFD-14#PBF
مشخصات دیتاشیت
| نام دیتاشیت | LTC2323-14 |
|---|---|
| حجم فایل | 1246.083 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 26 |
دانلود دیتاشیت LTC2323-14 |
LTC2323-14 Datasheet |
|---|
مشخصات
- RoHS: true
- Category: ADC/DAC/Data Conversion/Analog To Digital Converters (ADCs)
- Datasheet: Analog Devices LTC2323IUFD-14#PBF
- Interface: serial
- resolution: 14Bit
- Supply Voltage: 3.13V~3.47V;5V
- differential input: Yes
- number of channels: 2
- sampling frequency: 5MHz
- Operating Temperature: -40°C~+85°C
- Package: QFN-28-EP(4x5)
- Manufacturer: Analog Devices
- Series: -
- Packaging: Tube
- Part Status: Active
- Number of Bits: 14
- Sampling Rate (Per Second): 5M
- Number of Inputs: 2
- Input Type: Differential, Pseudo-Differential
- Data Interface: LVDS - Serial, Serial
- Configuration: S/H-ADC
- Ratio - S/H:ADC: 1:1
- Number of A/D Converters: 2
- Architecture: SAR
- Reference Type: External, Internal
- Voltage - Supply, Analog: 3.13V ~ 3.47V, 5V
- Voltage - Supply, Digital: 3.13V ~ 3.47V, 5V
- Features: Simultaneous Sampling
- Package / Case: 28-WFQFN Exposed Pad
- Supplier Device Package: 28-QFN (4x5)
- Mounting Type: Surface Mount
- Base Part Number: LTC2323
- detail: 14 Bit Analog to Digital Converter 2 Input 2 SAR 28-QFN (4x5)
