APTGL475DA120D3G دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت APTGL475DA120D3G	دانلود دیتاشیت

Manufacturer: Microchip Technology
Series: -
Packaging: Bulk
Part Status: Active
IGBT Type: Trench Field Stop
Configuration: Single
Voltage - Collector Emitter Breakdown (Max): 1200V
Current - Collector (Ic) (Max): 610A
Power - Max: 2080W
Vce(on) (Max) @ Vge, Ic: 2.2V @ 15V, 400A
Current - Collector Cutoff (Max): 5mA
Input Capacitance (Cies) @ Vce: 24.6nF @ 25V
Input: Standard
NTC Thermistor: No
Operating Temperature: -40°C ~ 175°C (TJ)
Mounting Type: Chassis Mount
Package / Case: D-3 Module
Supplier Device Package: D3
detail: IGBT Module Trench Field Stop Single 1200V 610A 2080W Chassis Mount D3
