دیتاشیت LT3065MPDD-2.5#PBF

LT3065 Datasheet

مشخصات دیتاشیت

نام دیتاشیت LT3065 Datasheet
حجم فایل 1715.65 کیلوبایت
نوع فایل pdf
تعداد صفحات 28

دانلود دیتاشیت LT3065 Datasheet

LT3065 Datasheet Datasheet

مشخصات

  • Manufacturer: Linear Technology/Analog Devices
  • Series: -
  • Packaging: Tube
  • Part Status: Active
  • Output Configuration: Positive
  • Output Type: Fixed
  • Number of Regulators: 1
  • Voltage - Input (Max): 45V
  • Voltage - Output (Min/Fixed): 2.5V
  • Voltage - Output (Max): -
  • Voltage Dropout (Max): 0.51V @ 500mA
  • Current - Output: 500mA
  • Current - Quiescent (Iq): 110µA
  • Current - Supply (Max): 25mA
  • PSRR: 72dB (120Hz)
  • Control Features: Current Limit, Enable, Power Good, Soft Start
  • Protection Features: Over Current, Over Temperature, Reverse Polarity
  • Operating Temperature: -55°C ~ 150°C
  • Mounting Type: Surface Mount
  • Package / Case: 10-WFDFN Exposed Pad
  • Supplier Device Package: 10-DFN (3x3)
  • Base Part Number: LT3065
  • detail: Linear Voltage Regulator IC 1 Output 500mA 10-DFN (3x3)
