APTM100UM65SCAVG دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
APTM100UM65SCAVG
|
|
حجم فایل
|
441.662
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
9
|
مشخصات فنی
-
Manufacturer:
Microchip Technology
-
Series:
POWER MOS 7®
-
Packaging:
Bulk
-
Part Status:
Active
-
FET Type:
N-Channel
-
Technology:
MOSFET (Metal Oxide)
-
Drain to Source Voltage (Vdss):
1000V
-
Current - Continuous Drain (Id) @ 25°C:
145A (Tc)
-
Drive Voltage (Max Rds On, Min Rds On):
10V
-
Rds On (Max) @ Id, Vgs:
78mOhm @ 72.5A, 10V
-
Vgs(th) (Max) @ Id:
5V @ 20mA
-
Gate Charge (Qg) (Max) @ Vgs:
1068nC @ 10V
-
Vgs (Max):
±30V
-
Input Capacitance (Ciss) (Max) @ Vds:
28500pF @ 25V
-
FET Feature:
-
-
Power Dissipation (Max):
3250W (Tc)
-
Operating Temperature:
-40°C ~ 150°C (TJ)
-
Mounting Type:
Chassis Mount
-
Supplier Device Package:
SP6
-
Package / Case:
Module
-
detail:
N-Channel 1000V 145A (Tc) 3250W (Tc) Chassis Mount SP6
