MSCMC120AM03CT6LIAG دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت MSCMC120AM03CT6LIAG	دانلود دیتاشیت

مستندات دیگری یافت نشد!

Manufacturer: Microchip Technology
Series: -
Part Status: Active
FET Type: 2 N Channel (Phase Leg)
FET Feature: Silicon Carbide (SiC)
Drain to Source Voltage (Vdss): 1200V (1.2kV)
Current - Continuous Drain (Id) @ 25°C: 631A (Tc)
Rds On (Max) @ Id, Vgs: 3.4mOhm @ 500A, 20V
Vgs(th) (Max) @ Id: 4V @ 150mA
Gate Charge (Qg) (Max) @ Vgs: 1610nC @ 20V
Input Capacitance (Ciss) (Max) @ Vds: 27900pF @ 1000V
Power - Max: 2778W (Tc)
Operating Temperature: -40°C ~ 175°C (TJ)
Mounting Type: Chassis Mount
Package / Case: Module
Supplier Device Package: SP6C LI
detail: Mosfet Array 2 N Channel (Phase Leg) 1200V (1.2kV) 631A (Tc) 2778W (Tc) Chassis Mount SP6C LI
