APTMC120TAM34CT3AG دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت APTMC120TAM34CT3AG	دانلود دیتاشیت

مستندات دیگری یافت نشد!

Manufacturer: Microchip Technology
Series: -
Packaging: Bulk
Part Status: Active
FET Type: 6 N-Channel (3-Phase Bridge)
FET Feature: Silicon Carbide (SiC)
Drain to Source Voltage (Vdss): 1200V (1.2kV)
Current - Continuous Drain (Id) @ 25°C: 74A (Tc)
Rds On (Max) @ Id, Vgs: 34mOhm @ 50A, 20V
Vgs(th) (Max) @ Id: 4V @ 15mA
Gate Charge (Qg) (Max) @ Vgs: 161nC @ 5V
Input Capacitance (Ciss) (Max) @ Vds: 2788pF @ 1000V
Power - Max: 375W
Operating Temperature: -40°C ~ 175°C (TJ)
Mounting Type: Chassis Mount
Package / Case: Module
Supplier Device Package: SP3
detail: Mosfet Array 6 N-Channel (3-Phase Bridge) 1200V (1.2kV) 74A (Tc) 375W Chassis Mount SP3
