دیتاشیت LTC2356CMSE-14#PBF

LTC2356-12/14

مشخصات دیتاشیت

نام دیتاشیت LTC2356-12/14
حجم فایل 530.702 کیلوبایت
نوع فایل pdf
تعداد صفحات 20

دانلود دیتاشیت LTC2356-12/14

LTC2356-12/14 Datasheet

مشخصات

  • RoHS: true
  • Category: ADC/DAC/Data Conversion/Analog To Digital Converters (ADCs)
  • Datasheet: Analog Devices LTC2356CMSE-14#PBF
  • Interface: SPI
  • resolution: 14Bit
  • Supply Voltage: 3.1V~3.6V
  • differential input: Yes
  • number of channels: 1
  • sampling frequency: 3.5MHz
  • Operating Temperature: 0°C~+70°C
  • Package: MSOP-10-EP
  • Manufacturer: Analog Devices
  • Series: -
  • Packaging: Tube
  • Part Status: Active
  • Number of Bits: 14
  • Sampling Rate (Per Second): 3.5M
  • Number of Inputs: 1
  • Input Type: Differential, Single Ended
  • Data Interface: SPI
  • Configuration: S/H-ADC
  • Ratio - S/H:ADC: 1:1
  • Number of A/D Converters: 1
  • Architecture: SAR
  • Reference Type: External, Internal
  • Voltage - Supply, Analog: 3.1V ~ 3.6V
  • Voltage - Supply, Digital: 3.1V ~ 3.6V
  • Features: -
  • Package / Case: 10-TFSOP, 10-MSOP (0.118", 3.00mm Width) Exposed Pad
  • Supplier Device Package: 10-MSOP-EP
  • Mounting Type: Surface Mount
  • Base Part Number: LTC2356
  • detail: 14 Bit Analog to Digital Converter 1 Input 1 SAR 10-MSOP-EP
