دیتاشیت LTC2205IUK#PBF

LTC2205, LTC2204

مشخصات دیتاشیت

نام دیتاشیت LTC2205, LTC2204
حجم فایل 1404.659 کیلوبایت
نوع فایل pdf
تعداد صفحات 36

دانلود دیتاشیت LTC2205, LTC2204

LTC2205, LTC2204 Datasheet

مشخصات

  • Manufacturer: Linear Technology/Analog Devices
  • Series: -
  • Packaging: Tube
  • Part Status: Active
  • Number of Bits: 16
  • Sampling Rate (Per Second): 65M
  • Number of Inputs: 1
  • Input Type: Differential
  • Data Interface: Parallel
  • Configuration: S/H-ADC
  • Ratio - S/H:ADC: 1:1
  • Number of A/D Converters: 1
  • Architecture: Pipelined
  • Reference Type: External, Internal
  • Voltage - Supply, Analog: 3.135V ~ 3.465V
  • Voltage - Supply, Digital: 3.135V ~ 3.465V
  • Features: PGA
  • Operating Temperature: -40°C ~ 85°C
  • Package / Case: 48-WFQFN Exposed Pad
  • Supplier Device Package: 48-QFN (7x7)
  • Mounting Type: Surface Mount
  • Base Part Number: LTC2205
  • detail: 16 Bit Analog to Digital Converter 1 Input 1 Pipelined 48-QFN (7x7)
