- دیتاشیت LTC1433IGN#PBF
LTC1433IGN#PBF دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | LTC1433IGN#PBF |
|---|---|
| حجم فایل | 119.398 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 20 |
دانلود دیتاشیت LTC1433IGN#PBF |
دانلود دیتاشیت |
|---|
سایر مستندات
LTC1433, LTC1434 20 pages
مشخصات فنی
- RoHS: true
- Category: Power Supply Chip/DC-DC Converters
- Function: Step-down type
- Topology: Step-down
- Datasheet: Analog Devices LTC1433IGN#PBF
- Output Type: Adjustable
- Input Voltage: 3V~13.5V
- Output Voltage: 1.19V~12V
- Number of Outputs: 1
- Switching Frequency: 700kHz
- Output Current (Max): 450mA
- Operating Temperature: -40°C~+85°C@(TA)
- Synchronous Rectification: NO
- Package: SSOP-16-150mil
- Manufacturer: Analog Devices
- Series: -
- Packaging: Tube
- Part Status: Active
- Output Configuration: Positive
- Voltage - Input (Min): 3V
- Voltage - Input (Max): 13.5V
- Voltage - Output (Min/Fixed): 1.19V (3.3V, 5V)
- Voltage - Output (Max): 12V
- Current - Output: 450mA
- Frequency - Switching: Up to 700kHz
- Synchronous Rectifier: No
- Mounting Type: Surface Mount
- Package / Case: 16-SSOP (0.154", 3.90mm Width)
- Supplier Device Package: 16-SSOP
- Base Part Number: LTC1433
- detail: Buck Switching Regulator IC Positive Adjustable (Programmable) 1.19V (3.3V, 5V) 1 Output 450mA 16-SSOP (0.154", 3.90mm Width)
