PIC16LC923T-04/L Datasheet
Datasheet specifications
| Datasheet's name | PIC16C9xx Series |
|---|---|
| File size | 1230.749 KB |
| File type | |
| Number of pages | 189 |
Download Datasheet PIC16C9xx Series |
Download Datasheet |
|---|
Other documentations
No other documentation was found!
Technical specifications
- Manufacturer: Microchip Technology
- Series: PIC® 16C
- Packaging: Tape & Reel (TR)
- Part Status: Obsolete
- Core Processor: PIC
- Core Size: 8-Bit
- Speed: 4MHz
- Connectivity: I²C, SPI
- Peripherals: LCD, POR, PWM, WDT
- Number of I/O: 25
- Program Memory Size: 7KB (4K x 14)
- Program Memory Type: OTP
- EEPROM Size: -
- RAM Size: 176 x 8
- Voltage - Supply (Vcc/Vdd): 2.5V ~ 6V
- Data Converters: -
- Oscillator Type: External
- Operating Temperature: 0°C ~ 70°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 68-LCC (J-Lead)
- Supplier Device Package: 68-PLCC (24.23x24.23)
- Base Part Number: PIC16LC923
- detail: PIC PIC® 16C Microcontroller IC 8-Bit 4MHz 7KB (4K x 14) OTP 68-PLCC (24.23x24.23)
