RoHS: true
Category: Power Supply Chip/DC-DC Converters
Function: Buck-boost type
Topology: Step-down-Boost
Datasheet: Analog Devices LTC3119MPFE#PBF
Output Type: Adjustable
Input Voltage: 2.5V~18V
Output Voltage: 0.8V~18V
Number of Outputs: 1
Switching Frequency: 2MHz
Output Current (Max): 5A
Operating Temperature: -55°C~+150°C@(TA)
Synchronous Rectification: Yes
Package: TSSOP-28-EP
Manufacturer: Analog Devices
Series: -
Packaging: Tube
Part Status: Active
Output Configuration: Positive
Voltage - Input (Min): 2.5V
Voltage - Input (Max): 18V
Voltage - Output (Min/Fixed): 0.8V
Voltage - Output (Max): 18V
Current - Output: 5A
Frequency - Switching: 400kHz ~ 2MHz
Synchronous Rectifier: Yes
Mounting Type: Surface Mount
Package / Case: 28-TSSOP (0.173", 4.40mm Width) Exposed Pad
Supplier Device Package: 28-TSSOP-EP
Base Part Number: LTC3119
detail: Buck-Boost Switching Regulator IC Positive Adjustable 0.8V 1 Output 5A 28-TSSOP (0.173", 4.40mm Width) Exposed Pad
