LTC7880EUKG#PBF دیتاشیت

مشخصات دیتاشیت

دانلود دیتاشیت LTC7880EUKG#PBF	دانلود دیتاشیت

LTC7880 116 pages

RoHS: true
Category: Power Supply Chip/DC-DC Controllers
Function: boost converterType
Topology: Boost
Datasheet: Analog Devices LTC7880EUKG#PBF
Input Voltage: 5V~40V
Duty Cycle (Max): 92%
Number of Outputs: 2
Switching Frequency: 500kHz
Operating Temperature: -40°C~+125°C@(TJ)
Synchronous Rectification: Yes
Package: QFN-52-EP(7x8)
Manufacturer: Analog Devices
Series: -
Part Status: Active
Output Type: Transistor Driver
Output Configuration: Positive
Output Phases: 2
Voltage - Supply (Vcc/Vdd): 5V ~ 40V
Frequency - Switching: 50kHz ~ 500kHz
Synchronous Rectifier: Yes
Clock Sync: Yes
Serial Interfaces: I²C, PMBus
Control Features: Current Limit, Enable, Soft Start
Mounting Type: Surface Mount
Package / Case: 52-WFQFN Exposed Pad
Supplier Device Package: 52-QFN (7x8)
detail: Boost Regulator Positive Output Step-Up I²C, PMBus DC-DC Controller IC 52-QFN (7x8)
