دیتاشیت LT3009ESC8-5#TRMPBF

LT3009 Series

مشخصات دیتاشیت

نام دیتاشیت LT3009 Series
حجم فایل 269.18 کیلوبایت
نوع فایل pdf
تعداد صفحات 20

دانلود دیتاشیت LT3009 Series

LT3009 Series Datasheet

مشخصات

  • Manufacturer: Linear Technology/Analog Devices
  • Series: -
  • Packaging: Tube
  • Part Status: Obsolete
  • Output Configuration: Positive
  • Output Type: Fixed
  • Number of Regulators: 1
  • Voltage - Input (Max): 20V
  • Voltage - Output (Min/Fixed): 5V
  • Voltage - Output (Max): -
  • Voltage Dropout (Max): 0.45V @ 20mA
  • Current - Output: 20mA
  • Current - Quiescent (Iq): 6µA
  • Current - Supply (Max): 1mA
  • PSRR: 56dB (120Hz)
  • Control Features: Enable
  • Protection Features: Over Current, Over Temperature, Reverse Polarity
  • Operating Temperature: -40°C ~ 125°C
  • Mounting Type: Surface Mount
  • Package / Case: 8-VFSOP (0.049", 1.25mm Width)
  • Supplier Device Package: SC-70
  • detail: Linear Voltage Regulator IC 1 Output 20mA SC-70
