LT8391 Datasheet دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
LT8391 Datasheet
|
|
حجم فایل
|
465.659
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
34
|
مشخصات فنی
-
RoHS:
true
-
Type:
DC-DCController
-
Dimming:
Analog;PWM
-
Category:
Nixie Tube Driver/LED Driver/LED Drivers
-
Channels:
1
-
Topology:
Step-down,boost converter
-
Datasheet:
Analog Devices LT8391IFE#PBF
-
Input Voltage:
4V~60V
-
Output Voltage:
60V
-
Switch Frequency:
150kHz~650kHz
-
Operating temperature:
-40°C~+125°C
-
Package:
TSSOP-28-EP
-
Manufacturer:
Analog Devices
-
Series:
-
-
Packaging:
Tube
-
Part Status:
Active
-
Internal Switch(s):
No
-
Number of Outputs:
1
-
Voltage - Supply (Min):
4V
-
Voltage - Supply (Max):
60V
-
Voltage - Output:
60V
-
Current - Output / Channel:
-
-
Frequency:
150kHz ~ 650kHz
-
Applications:
Automotive, Lighting
-
Mounting Type:
Surface Mount
-
Package / Case:
28-TSSOP (0.173", 4.40mm Width) Exposed Pad
-
Supplier Device Package:
28-TSSOP-EP
-
Base Part Number:
LT8391
-
detail:
LED Driver IC 1 Output DC DC Controller Step-Down (Buck), Step-Up (Boost) Analog, PWM Dimming 28-TSSOP-EP
