LTC2656 Datasheet

LTC2656

Datasheet specifications

Datasheet's name LTC2656
File size 1900.081 KB
File type pdf
Number of pages 26

Download Datasheet LTC2656

Download Datasheet

Other documentations

LTC2656BCUFD-H16#PBF 26 pages

Technical specifications

  • RoHS: true
  • Category: ADC/DAC/Data Conversion/Digital To Analog Converters (DACs)
  • Datasheet: Analog Devices LTC2656CIFE-L16#PBF
  • Interface: SPI
  • Resolution: 16Bit
  • Output Type: Voltage-缓冲
  • Settling Time: 8.9us
  • Supply Voltage: 2.7V~5.5V
  • Integral nonlinearity: ±6LSB;±0.3LSB
  • Operating Temperature: -40°C~+85°C
  • Package: TSSOP-20-EP
  • Manufacturer: Analog Devices
  • Series: -
  • Packaging: Tube
  • Part Status: Active
  • Number of Bits: 16
  • Number of D/A Converters: 8
  • Differential Output: No
  • Data Interface: SPI
  • Reference Type: External, Internal
  • Voltage - Supply, Analog: 2.7V ~ 5.5V
  • Voltage - Supply, Digital: 2.7V ~ 5.5V
  • INL/DNL (LSB): ±6, ±0.3
  • Architecture: -
  • Package / Case: 20-TSSOP (0.173", 4.40mm Width) Exposed Pad
  • Supplier Device Package: 20-TSSOP-EP
  • Mounting Type: Surface Mount
  • Base Part Number: LTC2656
  • detail: 16 Bit Digital to Analog Converter 8 20-TSSOP-EP
