دیتاشیت LT1931ES5#TRMPBF

LT1931(A)

مشخصات دیتاشیت

نام دیتاشیت LT1931(A)
حجم فایل 459.162 کیلوبایت
نوع فایل pdf
تعداد صفحات 12

دانلود دیتاشیت LT1931(A)

LT1931(A) Datasheet

مشخصات

  • RoHS: true
  • Category: Power Supply Chip/DC-DC Converters
  • Function: Buck-boost type
  • Topology: Cuk
  • Datasheet: Analog Devices LT1931ES5#TRMPBF
  • Output Type: Adjustable
  • Input Voltage: 2.45V~16V
  • Output Voltage: -34V~-1.255V
  • Number of Outputs: 1
  • Switching Frequency: 1.2MHz
  • Output Current (Max): 1A
  • Operating Temperature: 0°C~+70°C@(TA)
  • Synchronous Rectification: NO
  • Package: SOT-23-5
  • Manufacturer: Analog Devices
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Output Configuration: Negative
  • Voltage - Input (Min): 2.45V
  • Voltage - Input (Max): 16V
  • Voltage - Output (Min/Fixed): -1.255V
  • Voltage - Output (Max): -34V
  • Current - Output: 1A
  • Frequency - Switching: 1.2MHz
  • Synchronous Rectifier: No
  • Mounting Type: Surface Mount
  • Package / Case: SOT-23-5 Thin, TSOT-23-5
  • Supplier Device Package: TSOT-23-5
  • Base Part Number: LT1931
  • detail: Cuk Switching Regulator IC Negative Adjustable -1.255V 1 Output 1A SOT-23-5 Thin, TSOT-23-5
