دیتاشیت LTC3129EMSE-1#PBF
مشخصات دیتاشیت
| نام دیتاشیت | LTC3129-1 |
|---|---|
| حجم فایل | 1674.904 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 30 |
دانلود دیتاشیت LTC3129-1 |
LTC3129-1 Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/DC-DC Converters
- Function: Buck-boost type
- Topology: Step-down-Boost
- Datasheet: Analog Devices LTC3129EMSE-1#PBF
- Output Type: Adjustable
- Input Voltage: 1.92V~15V
- Output Voltage: 2.5V~15V
- Number of Outputs: 1
- Switching Frequency: 1.2MHz
- Output Current (Max): 200mA
- Operating Temperature: -40°C~+125°C@(TJ)
- Synchronous Rectification: Yes
- Package: MSOP-16-EP
- Manufacturer: Analog Devices
- Series: -
- Packaging: Tube
- Part Status: Active
- Output Configuration: Positive
- Voltage - Input (Min): 1.92V
- Voltage - Input (Max): 15V
- Voltage - Output (Min/Fixed): 2.5V
- Voltage - Output (Max): 15V
- Current - Output: 200mA
- Frequency - Switching: 1.2MHz
- Synchronous Rectifier: Yes
- Mounting Type: Surface Mount
- Package / Case: 16-TFSOP (0.118", 3.00mm Width) Exposed Pad
- Supplier Device Package: 16-MSOP-EP
- Base Part Number: LTC3129
- detail: Buck-Boost Switching Regulator IC Positive Programmable 2.5V 1 Output 200mA 16-TFSOP (0.118", 3.00mm Width) Exposed Pad
