LT1618 Datasheet دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
LT1618 Datasheet
|
|
حجم فایل
|
215.224
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
16
|
مشخصات فنی
-
RoHS:
true
-
Category:
Power Supply Chip/DC-DC Converters
-
Function:
boost converterType
-
Topology:
Boost
-
Datasheet:
Analog Devices LT1618EDD#TRPBF
-
Output Type:
Adjustable
-
Input Voltage:
1.6V~18V
-
Output Voltage:
1.263V~36V
-
Number of Outputs:
1
-
Switching Frequency:
1.4MHz
-
Output Current (Max):
1.5A
-
Operating Temperature:
0°C~+70°C@(TA)
-
Synchronous Rectification:
NO
-
Package:
DFN-10(3x3)
-
Manufacturer:
Analog Devices
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Output Configuration:
Positive
-
Voltage - Input (Min):
1.6V
-
Voltage - Input (Max):
18V
-
Voltage - Output (Min/Fixed):
1.263V
-
Voltage - Output (Max):
36V (Switch)
-
Current - Output:
1.5A (Switch)
-
Frequency - Switching:
1.4MHz
-
Synchronous Rectifier:
No
-
Mounting Type:
Surface Mount
-
Package / Case:
10-WFDFN Exposed Pad
-
Supplier Device Package:
10-DFN (3x3)
-
Base Part Number:
LT1618
-
detail:
Boost Switching Regulator IC Positive Adjustable 1.263V 1 Output 1.5A (Switch) 10-WFDFN Exposed Pad
