دیتاشیت LT3480IDD#TRPBF
مشخصات دیتاشیت
| نام دیتاشیت |
LT3480
|
| حجم فایل |
388.327
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
24
|
مشخصات
-
RoHS:
true
-
Category:
Power Supply Chip/DC-DC Converters
-
Function:
Step-down type
-
Topology:
Step-down
-
Datasheet:
Analog Devices LT3480IDD#TRPBF
-
Output Type:
Adjustable
-
Input Voltage:
3.6V~36V
-
Output Voltage:
0.79V~20V
-
Number of Outputs:
1
-
Switching Frequency:
2.4MHz
-
Output Current (Max):
2A
-
Operating Temperature:
-40°C~+125°C@(TJ)
-
Synchronous Rectification:
NO
-
Package:
DFN-10(3x3)
-
Manufacturer:
Analog Devices
-
Series:
-
-
Part Status:
Active
-
Output Configuration:
Positive
-
Voltage - Input (Min):
3.6V
-
Voltage - Input (Max):
36V
-
Voltage - Output (Min/Fixed):
0.79V
-
Voltage - Output (Max):
20V
-
Current - Output:
2A
-
Frequency - Switching:
200kHz ~ 2.4MHz
-
Synchronous Rectifier:
No
-
Mounting Type:
Surface Mount
-
Package / Case:
10-WFDFN Exposed Pad
-
Supplier Device Package:
10-DFN (3x3)
-
Base Part Number:
LT3480
-
detail:
Buck Switching Regulator IC Positive Adjustable 0.79V 1 Output 2A 10-WFDFN Exposed Pad
