دیتاشیت LTC3114IDHC-1#TRPBF

مشخصات دیتاشیت

دانلود دیتاشیت LTC3114-1 Datasheet	LTC3114-1 Datasheet Datasheet

Manufacturer: Linear Technology/Analog Devices
Series: -
Packaging: Cut Tape (CT)
Part Status: Active
Function: Step-Up/Step-Down
Output Configuration: Positive
Topology: Buck-Boost
Output Type: Adjustable
Number of Outputs: 1
Voltage - Input (Min): 2.2V
Voltage - Input (Max): 40V
Voltage - Output (Min/Fixed): 2.7V
Voltage - Output (Max): 40V
Current - Output: 1A
Frequency - Switching: 1.2MHz
Synchronous Rectifier: Yes
Operating Temperature: -40°C ~ 125°C (TJ)
Mounting Type: Surface Mount
Package / Case: 16-WFDFN Exposed Pad
Supplier Device Package: 16-DFN (5x3)
Base Part Number: LTC3114
detail: Buck-Boost Switching Regulator IC Positive Adjustable 2.7V 1 Output 1A 16-WFDFN Exposed Pad
