دیتاشیت LTC2309IUF#TRPBF

LTC2309 Datasheet

مشخصات دیتاشیت

نام دیتاشیت LTC2309 Datasheet
حجم فایل 1690.938 کیلوبایت
نوع فایل pdf
تعداد صفحات 26

دانلود دیتاشیت LTC2309 Datasheet

LTC2309 Datasheet Datasheet

مشخصات

  • RoHS: true
  • Category: ADC/DAC/Data Conversion/Analog To Digital Converters (ADCs)
  • Datasheet: Analog Devices LTC2309IUF#TRPBF
  • Interface: I2C
  • resolution: 12Bit
  • Supply Voltage: 5V
  • differential input: Yes
  • number of channels: 8
  • sampling frequency: 14kHz
  • Operating Temperature: -40°C~+85°C
  • Package: QFN-24-EP(4x4)
  • Manufacturer: Analog Devices
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Number of Bits: 12
  • Sampling Rate (Per Second): 14k
  • Number of Inputs: 8
  • Input Type: Differential, Single Ended
  • Data Interface: I²C
  • Configuration: MUX-S/H-ADC
  • Ratio - S/H:ADC: 1:1
  • Number of A/D Converters: 1
  • Architecture: SAR
  • Reference Type: External, Internal
  • Voltage - Supply, Analog: 5V
  • Voltage - Supply, Digital: 5V
  • Features: Selectable Address
  • Package / Case: 24-WFQFN Exposed Pad
  • Supplier Device Package: 24-QFN (4x4)
  • Mounting Type: Surface Mount
  • Base Part Number: LTC2309
  • detail: 12 Bit Analog to Digital Converter 8 Input 1 SAR 24-QFN (4x4)
