دیتاشیت U6815BM-MFL
مشخصات دیتاشیت
| نام دیتاشیت |
U6815BM
|
| حجم فایل |
1071.564
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
14
|
مشخصات
-
Manufacturer:
Microchip Technology
-
Series:
-
-
Packaging:
Tube
-
Part Status:
Obsolete
-
Switch Type:
General Purpose
-
Number of Outputs:
12
-
Ratio - Input:Output:
1:12
-
Output Configuration:
High Side or Low Side
-
Output Type:
N/P-Channel
-
Interface:
SPI
-
Voltage - Load:
40V (Max)
-
Voltage - Supply (Vcc/Vdd):
4.5V ~ 5.5V
-
Current - Output (Max):
600mA
-
Rds On (Typ):
2Ohm (Max), 1.5Ohm (Max)
-
Input Type:
-
-
Features:
-
-
Fault Protection:
Current Limiting (Fixed), Open Load Detect, Over Temperature, Over Voltage
-
Operating Temperature:
-40°C ~ 150°C (TJ)
-
Mounting Type:
Surface Mount
-
Supplier Device Package:
28-SO
-
Package / Case:
28-SOIC (0.295", 7.50mm Width)
-
Base Part Number:
U6815B
-
detail:
Power Switch/Driver 1:12 N/P-Channel 600mA 28-SO
