LTC3807 دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
LTC3807
|
|
حجم فایل
|
571.631
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
34
|
مشخصات فنی
-
Manufacturer:
Linear Technology/Analog Devices
-
Series:
-
-
Part Status:
Active
-
Output Type:
Transistor Driver
-
Function:
Step-Down
-
Output Configuration:
Positive
-
Topology:
Buck
-
Number of Outputs:
1
-
Output Phases:
1
-
Voltage - Supply (Vcc/Vdd):
4V ~ 38V
-
Frequency - Switching:
50kHz ~ 900kHz
-
Duty Cycle (Max):
99%
-
Synchronous Rectifier:
Yes
-
Clock Sync:
No
-
Serial Interfaces:
-
-
Control Features:
Current Limit, Enable, Frequency Control, Soft Start, Tracking
-
Operating Temperature:
-40°C ~ 125°C (TJ)
-
Mounting Type:
Surface Mount
-
Package / Case:
20-WFQFN Exposed Pad
-
Supplier Device Package:
20-QFN (3x4)
-
Base Part Number:
LTC3807
-
detail:
Buck Regulator Positive Output Step-Down DC-DC Controller IC 20-QFN (3x4)
