- دیتاشیت High Performance LDOs Selector Card
High Performance LDOs Selector Card دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | High Performance LDOs Selector Card |
|---|---|
| حجم فایل | 1031.942 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 2 |
دانلود دیتاشیت High Performance LDOs Selector Card |
دانلود دیتاشیت |
|---|
سایر مستندات
LT3045IMSE-1#PBF 32 pages
LT3045 Datasheet 32 pages
مشخصات فنی
- RoHS: true
- Category: Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet: Analog Devices LT3045IDD#TRPBF
- Output Type: Adjustable
- Output Current: 500mA
- Output Voltage: 0V~15V
- Dropout Voltage: 0.45V@(500mA)
- Output Polarity: positive
- Number of Outputs: 1
- Maximum Input Voltage: 20V
- Operating Temperature: -40°C~+125°C@(Tj)
- Quiescent Current (Ground Current): 20uA
- Package: DFN-10(3x3)
- Manufacturer: Analog Devices
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Output Configuration: Positive
- Number of Regulators: 1
- Voltage - Input (Max): 20V
- Voltage - Output (Min/Fixed): 0V
- Voltage - Output (Max): 15V
- Voltage Dropout (Max): 0.45V @ 500mA
- Current - Output: 500mA
- Current - Quiescent (Iq): 20µA
- Current - Supply (Max): 25mA
- PSRR: 117dB ~ 53dB (120Hz ~ 10MHz)
- Control Features: Enable, Power Good, Soft Start
- Protection Features: Over Current, Over Temperature, Reverse Polarity, Under Voltage Lockout (UVLO)
- Mounting Type: Surface Mount
- Package / Case: 10-WFDFN Exposed Pad
- Supplier Device Package: 10-DFN (3x3)
- Base Part Number: LT3045
- detail: Linear Voltage Regulator IC 1 Output 500mA 10-DFN (3x3)
