دیتاشیت LTC3411AEMS#TRPBF

مشخصات دیتاشیت

دانلود دیتاشیت LTC3411A	LTC3411A Datasheet

RoHS: true
Category: Power Supply Chip/DC-DC Converters
Function: Step-down type
Topology: Step-down
Datasheet: Analog Devices LTC3411AEMS#TRPBF
Output Type: Adjustable
Input Voltage: 2.5V~5.5V
Output Voltage: 0.8V~5V
Number of Outputs: 1
Switching Frequency: 2.5MHz
Output Current (Max): 1.25A
Operating Temperature: -40°C~+125°C@(TJ)
Synchronous Rectification: Yes
Package: MSOP-10
Manufacturer: Analog Devices
Series: -
Packaging: Cut Tape (CT)
Part Status: Active
Output Configuration: Positive
Voltage - Input (Min): 2.5V
Voltage - Input (Max): 5.5V
Voltage - Output (Min/Fixed): 0.8V
Voltage - Output (Max): 5V
Current - Output: 1.25A
Frequency - Switching: 2.5MHz
Synchronous Rectifier: Yes
Mounting Type: Surface Mount
Package / Case: 10-TFSOP, 10-MSOP (0.118", 3.00mm Width)
Supplier Device Package: 10-MSOP
Base Part Number: LTC3411
detail: Buck Switching Regulator IC Positive Adjustable 0.8V 1 Output 1.25A 10-TFSOP, 10-MSOP (0.118", 3.00mm Width)
