دیتاشیت MCP1701-3302I/TO

MCP1701

مشخصات دیتاشیت

نام دیتاشیت MCP1701
حجم فایل 252.308 کیلوبایت
نوع فایل pdf
تعداد صفحات 20

دانلود دیتاشیت MCP1701

MCP1701 Datasheet

مشخصات

  • Manufacturer: Microchip Technology
  • Series: -
  • Packaging: Bulk
  • Part Status: Obsolete
  • Output Configuration: Positive
  • Output Type: Fixed
  • Number of Regulators: 1
  • Voltage - Input (Max): 10V
  • Voltage - Output (Min/Fixed): 3.3V
  • Voltage - Output (Max): -
  • Voltage Dropout (Max): 0.7V @ 160mA
  • Current - Output: 150mA
  • Current - Quiescent (Iq): 3µA
  • PSRR: -
  • Control Features: -
  • Protection Features: Short Circuit
  • Operating Temperature: -40°C ~ 85°C
  • Mounting Type: Through Hole
  • Package / Case: TO-226-3, TO-92-3 (TO-226AA)
  • Supplier Device Package: TO-92-3
  • Base Part Number: MCP1701
  • detail: Linear Voltage Regulator IC 1 Output 150mA TO-92-3
