LT1270/A 数据手册
其他文档
LT1270ACT#PBF 4 pages
技术规格
- RoHS: true
- Category: Power Supply Chip/DC-DC Converters
- Function: boost converterType;Step-down type;Buck-boost type
- Topology: Step-down;Boost;Flyback
- Datasheet: Analog Devices LT1270CT#PBF
- Output Type: Adjustable
- Input Voltage: 3.5V~30V
- Output Voltage: 1.244V~60V
- Number of Outputs: 1
- Switching Frequency: 60kHz
- Output Current (Max): 8A
- Operating Temperature: 0°C~+125°C@(TJ)
- Synchronous Rectification: NO
- Package: TO-220-5
- Manufacturer: Analog Devices
- Series: -
- Packaging: Tube
- Part Status: Active
- Output Configuration: Positive or Negative
- Voltage - Input (Min): 3.5V
- Voltage - Input (Max): 30V
- Voltage - Output (Min/Fixed): 1.244V
- Voltage - Output (Max): 60V (Switch)
- Current - Output: 8A (Switch)
- Frequency - Switching: 60kHz
- Synchronous Rectifier: No
- Mounting Type: Through Hole
- Package / Case: TO-220-5 Formed Leads
- Supplier Device Package: TO-220-5
- Base Part Number: LT1270
- detail: Buck, Boost, Flyback Switching Regulator IC Positive or Negative Adjustable 1.244V 1 Output 8A (Switch) TO-220-5 Formed Leads
