دیتاشیت DG408MY/PR-T

DG408-09

مشخصات دیتاشیت

نام دیتاشیت DG408-09
حجم فایل 138.775 کیلوبایت
نوع فایل pdf
تعداد صفحات 12

دانلود دیتاشیت DG408-09

DG408-09 Datasheet

مشخصات

  • Multiplexer/Demultiplexer Circuit: 8:1
  • Part Status: Obsolete
  • Charge Injection: 2pC
  • -3db Bandwidth: -
  • Operating Temperature: -55°C ~ 125°C (TA)
  • Voltage - Supply, Dual (V±): ±5V ~ 20V
  • Supplier Device Package: 16-SO
  • Package / Case: 16-SOIC (0.154", 3.90mm Width)
  • Switch Time (Ton, Toff) (Max): 150ns, 150ns
  • Packaging: Tape & Reel (TR)
  • Channel-to-Channel Matching (ΔRon): 1.5Ohm
  • Voltage - Supply, Single (V+): 5V ~ 30V
  • Channel Capacitance (CS(off), CD(off)): 3pF, 26pF
  • Switch Circuit: -
  • Mounting Type: Surface Mount
  • Series: -
  • Crosstalk: -92dB @ 100kHz
  • Number of Circuits: 1
  • Manufacturer: Maxim Integrated
  • Current - Leakage (IS(off)) (Max): 500pA
  • Base Part Number: DG408
  • On-State Resistance (Max): 100Ohm
  • detail: 1 Circuit IC Switch 8:1 100Ohm 16-SO
