دیتاشیت LTC7060JMSE#WPBF

LTC7060

مشخصات دیتاشیت

نام دیتاشیت LTC7060
حجم فایل 2275.804 کیلوبایت
نوع فایل pdf
تعداد صفحات 18

دانلود دیتاشیت LTC7060

LTC7060 Datasheet

مشخصات

  • Manufacturer: Linear Technology/Analog Devices
  • Series: -
  • Packaging: Tube
  • Part Status: Active
  • Output Configuration: Half Bridge (2)
  • Applications: General Purpose
  • Interface: PWM
  • Load Type: Capacitive
  • Technology: Power MOSFET
  • Rds On (Typ): 1.5Ohm LS, 1.5mOhm HS
  • Current - Output / Channel: -
  • Current - Peak Output: 6A
  • Voltage - Supply: 6V ~ 14V
  • Voltage - Load: 6V ~ 14V
  • Operating Temperature: -40°C ~ 150°C (TJ)
  • Features: Bootstrap Circuit
  • Fault Protection: Shoot-Through, UVLO
  • Mounting Type: Surface Mount
  • Package / Case: 12-TSSOP (0.118", 3.00mm Width) Exposed Pad
  • Supplier Device Package: 12-MSOP-EP
  • detail: Half Bridge (2) Driver General Purpose Power MOSFET 12-MSOP-EP
