MIC2171BT دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
MIC2171
|
|
حجم فایل
|
190.216
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
12
|
مشخصات فنی
-
Manufacturer:
Microchip Technology
-
Series:
-
-
Packaging:
Bulk
-
Part Status:
Obsolete
-
Function:
Step-Up, Step-Down, Step-Up/Step-Down
-
Output Configuration:
Positive or Negative, Isolation Capable
-
Topology:
Buck, Boost, Cuk, Flyback, Forward Converter
-
Output Type:
Adjustable
-
Number of Outputs:
1
-
Voltage - Input (Min):
3V
-
Voltage - Input (Max):
40V
-
Voltage - Output (Min/Fixed):
-
-
Voltage - Output (Max):
65V (Switch)
-
Current - Output:
2.5A (Switch)
-
Frequency - Switching:
100kHz
-
Synchronous Rectifier:
No
-
Operating Temperature:
-40°C ~ 85°C (TA)
-
Mounting Type:
Through Hole
-
Package / Case:
TO-220-5
-
Supplier Device Package:
TO-220-5
-
Base Part Number:
MIC2171
-
detail:
Buck, Boost, Cuk, Flyback, Forward Converter Switching Regulator IC Positive or Negative, Isolation Capable Adjustable 1 Output 2.5A (Switch) TO-220-5
