دیتاشیت MIC2077-1BWM
مشخصات دیتاشیت
| نام دیتاشیت |
MIC2077-1BWM
|
| حجم فایل |
1428.057
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
17
|
مشخصات فنی
-
Manufacturer:
Microchip Technology
-
Series:
-
-
Packaging:
Tube
-
Part Status:
Obsolete
-
Switch Type:
USB Switch
-
Number of Outputs:
4
-
Ratio - Input:Output:
2 x 1:2
-
Output Configuration:
High Side
-
Output Type:
N-Channel
-
Interface:
On/Off
-
Voltage - Load:
2.7V ~ 5.5V
-
Voltage - Supply (Vcc/Vdd):
Not Required
-
Current - Output (Max):
500mA
-
Rds On (Typ):
100mOhm
-
Input Type:
Non-Inverting
-
Features:
Slew Rate Controlled, Status Flag
-
Fault Protection:
Current Limiting (Fixed), Over Temperature, UVLO
-
Operating Temperature:
-40°C ~ 85°C (TA)
-
Mounting Type:
Surface Mount
-
Supplier Device Package:
16-SOIC
-
Package / Case:
16-SOIC (0.295", 7.50mm Width)
-
Base Part Number:
MIC2077
-
detail:
Power Switch/Driver 2 x 1:2 N-Channel 500mA 16-SOIC
