MIC2537-1BM Datasheet

MIC2537

Datasheet specifications

Datasheet's name MIC2537
File size 85.587 KB
File type pdf
Number of pages 12

Download Datasheet MIC2537

Download Datasheet

Other documentations

No other documentation was found!

Technical specifications

  • Manufacturer: Microchip Technology
  • Series: -
  • Packaging: Tube
  • Part Status: Discontinued at Digi-Key
  • Switch Type: USB Switch
  • Number of Outputs: 4
  • Ratio - Input:Output: 1:4
  • Output Configuration: High Side
  • Output Type: N-Channel
  • Interface: On/Off
  • Voltage - Load: 3V ~ 5.5V
  • Voltage - Supply (Vcc/Vdd): Not Required
  • Current - Output (Max): 150mA
  • Rds On (Typ): 425mOhm
  • Input Type: Non-Inverting
  • Features: Slew Rate Controlled, Status Flag
  • Fault Protection: Current Limiting (Fixed), Over Temperature
  • Operating Temperature: -40°C ~ 85°C (TA)
  • Mounting Type: Surface Mount
  • Supplier Device Package: 16-SOIC
  • Package / Case: 16-SOIC (0.154", 3.90mm Width)
  • Base Part Number: MIC2537
  • detail: Power Switch/Driver 1:4 N-Channel 150mA 16-SOIC
