دیتاشیت MIC2568-1BTS-TR

MIC2568

مشخصات دیتاشیت

نام دیتاشیت MIC2568
حجم فایل 118.147 کیلوبایت
نوع فایل pdf
تعداد صفحات 10

دانلود دیتاشیت MIC2568

MIC2568 Datasheet

مشخصات

  • Manufacturer: Microchip Technology
  • Series: -
  • Packaging: Tape & Reel (TR)
  • Part Status: Discontinued at Digi-Key
  • Switch Type: PCMCIA Switch
  • Number of Outputs: 4
  • Ratio - Input:Output: 1:1
  • Output Configuration: High Side
  • Output Type: N-Channel
  • Interface: Logic
  • Voltage - Load: 3.3V, 5V
  • Voltage - Supply (Vcc/Vdd): Not Required
  • Current - Output (Max): 120mA
  • Rds On (Typ): 1.4Ohm
  • Input Type: Non-Inverting
  • Features: -
  • Fault Protection: Current Limiting (Fixed), Over Temperature
  • Operating Temperature: -40°C ~ 85°C (TA)
  • Mounting Type: Surface Mount
  • Supplier Device Package: 28-TSSOP
  • Package / Case: 28-TSSOP (0.173", 4.40mm Width)
  • Base Part Number: MIC2568
  • detail: Power Switch/Driver 1:1 N-Channel 120mA 28-TSSOP
