دیتاشیت MIC4685-3.3BR

MIC4685

مشخصات دیتاشیت

نام دیتاشیت MIC4685
حجم فایل 339.185 کیلوبایت
نوع فایل pdf
تعداد صفحات 17

دانلود دیتاشیت MIC4685

MIC4685 Datasheet

مشخصات

  • Manufacturer: Microchip Technology
  • Series: SuperSwitcher™
  • Packaging: Bulk
  • Part Status: Obsolete
  • Function: Step-Down
  • Output Configuration: Positive
  • Topology: Buck
  • Output Type: Fixed
  • Number of Outputs: 1
  • Voltage - Input (Min): 4V
  • Voltage - Input (Max): 30V
  • Voltage - Output (Min/Fixed): 3.3V
  • Voltage - Output (Max): -
  • Current - Output: 3A
  • Frequency - Switching: 200kHz
  • Synchronous Rectifier: No
  • Operating Temperature: -40°C ~ 125°C (TJ)
  • Mounting Type: Surface Mount
  • Package / Case: SPak-7 (7 leads + Tab)
  • Supplier Device Package: S-PAK-7
  • Base Part Number: MIC4685
  • detail: Buck Switching Regulator IC Positive Fixed 3.3V 1 Output 3A SPak-7 (7 leads + Tab)
